Ei100S Ionisation Smoke Alarm

Dual Ionisation chamber
Built-in ‘Test’ and ‘Hush’ buttons
Low power cell warning
Kitemarked to BS EN14604:2005
5 year guarantee

Suitable for:
British Standards Code

Product Description

The Ei100S Ionisation Smoke Alarm is powered by a 9V battery. The alarm gives a fire warning when adequate smoke enters the alarm.

Operation of the Ei100S Ionisation Smoke Alarm

  • The ‘Test’ button will perform a self test and sound the horn.
  • The ‘Hush’ button will silence false alarms. The unit will then beep once every 40 seconds for 10 minutes to indicate it is in ‘Hush’ mode.
  • The alarm will emit a beep every 40 seconds to indicate that the battery is depleted and needs replacing.

Technical Specification

  • The smoke alarm carries the BSI Kitemark to indicate type testing to BS EN14604:2005. It will meet the requirements of Grade F systems as defined in BS 5839: Part 6: 2013. It carries the CE mark to indicate conformance to Electrical Safety and Electromagnetic Compatibility Directives.
  • Dual ionisation chamber sensor, with corrosion resistant electrodes, and insect resistant cover.
  • Built-in sounder giving a minimum sound output of 85dB (A) at 3m. Frequency range 2200/2800Hz. The diameter of the piezo disc in the sounder measures 40mm, and has wire contacts soldered directly on to the piezo disc. The sounder includes a resonator or ‘trumpet’ 30mm in length, which reaches to the lid of the outer casing in order to amplify the sound.
  • ‘Test’ button simulates the effects of smoke and tests sensor, electronics and horn.
  • Automatic ‘Self-Test’: Smoke chamber is tested every 40 seconds and unit bleeps if a fault is detected.
  • Automatic reset facility – When smoke clears from the sensor, the smoke alarm will reset automatically.
  • Battery fitted with reliable snap fit connector, which prevents the battery being connected up the wrong way round. It also overcomes the problem of creepage.
  • Low battery warning signal, bleeps every minute for 30 days – when replacement battery is required.
  • Airspeed: No effect.
  • Ambient Temperature Range: 4°C to 40°C. Humidity Range: 0 to 90% relative humidity.
  • Dimensions: 140 x 125 x 46mm. Weight inclusive of packaging: 220g.
  • Manufactured in Ireland.
  • 5 year guarantee.

Downloads

Ei100S Data Sheet

Download

Ei100S Instructions

Download
